Product Description

TM1077 is a silver filled, solvent free, one component die attach adhesive that remains stretchable following thermal cure. This conductive adhesive was designed for large dies and accommodates thermomechanical stresses arising from differences in the thermal expansion coefficients between components. TM1077 is highly thermally conductive and can be used in a broad range of applications including aerospace, defense, lighting, energy and medical electronics.

Product Benefits

TM1077 is compatible with large die, and applications with high CTE mismatch. It can be used with high volume automated dispensing processes, and can be cured rapidly with low shrinkage. The cured material displays outstanding thermal and electrical conductivity, with a unique combination of high flexibility, high die shear strength after significant thermal cycling, and high adhesion to a broad range of materials. The cured material provides stress relief for bonding dissimilar materials which enables high reliability performance metrics such as high resistance to shock and cyclic fatigue.

Custom fills are available.

Please contact ACI.


Your Rating



Stretchable Die Attach Adhesive

Highest stretch for large component attach.
